hard material pelletizing-2
180团粒造粒线20190111.217
hard material pelletizing-3
hard material pelletizing-1
hard material pelletizing-4


RIGID MATERIAL PELLETIZING MACHINE

INTRODUCTION:

1.Formula: store and download the setting parameters of temperature and speed for next use

2.Automatic temperature control, heating / cooling

3.One key setting: for heating or heat preservation

4.All the temperature upper limit value can be set by one step at the same time, when it reaches the upper limit, an alarm will be given and the corresponding area will change color

5.Locking extruder while temperature deviation: low temperature protection, prevent starting up when temperature is not reached

6.Temperature control, all on or all off

7.Appointment for heating the host



SINGLE STAGE

Model

Dia of Screw (mm)

L/D Ratio

Motor Power (KW)

Capacity (kg/h)

ACM-H80

80

32

55

120-160

ACM-H100

100

32

110

260-350

ACM-H120

120

32

132

330-420

ACM-H150

150

32

185

450-560

ACM-H180

180

32

250

650-800

ACM-H200

200

32

315

800-1000



DOUBLE STAGES

Model

Dia of Screw (mm)

L/D Ratio

Motor Power (KW)

Capacity (kg/h)

ACM-HD100/120

ACM-H100

100

28

110

260-350

ACM120

120

10

30

ACM-HD120/150

ACM-H120

120

28

132

330-420

ACM150

150

10

37

ACM-HD150/180

ACM-H150

150

28

185/200

550-650

ACM180

180

10

45

ACM-HD180/200

ACM-H180

180

28

250/315

800-1000

ACM200

200

10

55
