You are here: Home » PRODUCTS » RECYCLING LINE » AGGLOMERATION PELLETIZING LINE
agglomeration pelletizing line-1
AGGLOMERATOR PELLETIZING
agglomeration pelletizing line-3
agglomeration pelletizing line-4
agglomeration pelletizing line-5



AGGLOMERATION PELLETIZING MACHINE





INTRODUCTION

1. ACM series pelletizing system combines crushing, compressing, plasticization and pelletizing;

2. Applied for plastic film, fiber, PET wasted silk, plastic bag, non-woven bag, and foaming material recycling and pelletizing.

3. Final product is granule and pellet, two shapes. Can be used for film blowing, pipe extrusion and injection.



SINGLE STAGE PELLETIZING

Model

Compactor

Single Screw Extruder

Capacity (KG/H)

Volume(L)

Motor Power(kW)

Diameter of Screw (MM)

L/D

Motor Power(kW)

ACM-S300/80

300

37

80

36

45/55

160-220

ACM-S500/100

500

55

100

36

90/110

300-380

ACM-S800/120

800

90

120

36

132

450-480

ACM-S1000/140

1000

110

140

36

160/185

500-650

ACM-S1200/160

1200

132

160

34

220/250

800-1000

ACM-S1400/180

1400

160

180

34

315

1000-1200



DOUBLE STAGE PELLETIZING

Model



Screw Diameter (MM)

L/D

Motor Power(kW)

Capacity (KG/H)

ACM-SD80/120

ACM-S300/80

80

36

45/55

160-220

ACM-120

120

10

22

ACM-SD100/120

ACM-S500/100

100

36

90/110

300-380

ACM-120

120

10

30

ACM-SD120/150

ACM-S800/120

120

36

132

450-480

ACM-150

150

10

37

ACM-SD140/150

ACM-S1000/140

140

36

160/185

500-650

ACM-150

150

10

45

ACM-SD160/180

ACM-S1200/160

160

34

220/250

800-1000

ACM-180

180

10

55

ACM-SD180/200

ACM-S1400/180

180

34

315

1000-1200

ACM-200

200

10

75
