INTRODUCTION:
1. Long groove between feed throat and screw to improve output highly.
2. Accurate temperature control system on feed section to match different plastics.
3. Unique screw design to achieve higher plasticizing and products quality.
4. Gearbox of high torsion balance to realize stable running.
5. H shape frame to decrease vibrating.
6. PLC (Simatic Multi Panel) operation panel to ensure synchronization.
7. Energy conservation, easy to maintenance.

PARAMETERS:

Pipe Range	16-63	20-63 (Double)	20-160	50-250	110-315	160-450	250-630	315-800	500-1200
Extruder Mode	BRD50/40	BRD60/40	BRD60/40	BRD75/40	BRD75/40	BRD90/40	BRD90/40	BRD90/40	BRD120/40
L/D Ratio	40	40	40	40	40	40	40	40	40
Main Motor (kw)	55	90	110	160	160	250	250	280	355
Max. Output (kg/h)	250	450	500	650	650	1000	1000	1100	1300
